Q900A-6150 Hydrogen Oxygen Electrolyzer

Introduction

The 900ml A Series Dual-Output Hydrogen-Oxygen Electrolyzer is composed of six layers of 150ml PEM proton exchange membranes stacked together. It utilizes independently developed  chemical deposition (ELD) proton exchange membrane, which are stable and reliable in quality, ensuring stable hydrogen production. Its appearance is simple and elegant, with dependable performance.

Specification

Product Parameters



Nominal hydrogen gas production per minute900ml/min
Nominal gases production per minuteH2:900±45ml/min, O2:450±25ml/min.
Working mediumPurified water(TDS<5PPM)
Inlet water pressure≤0.5MPa (≤72.52psi)
Overall size L*W*H96X90X74mm
Sizes of mounting holesM5 * 4pcs
Sizes of inlet/outlet holesΦ1/4” quick connector
Type of power supplyConstant current power
Rated voltage/currentDC18V / 20A
Acceptable working voltage/currentDC≤36V / ≤22A
Working water Pure water with TDS less than 5ppm,water temperature above 0℃&below 45℃
Water supply method Between the water tank and the module, the circulating pump supplies pressurized water for circulation, with a pressure of less than 0.5MPa and a flow rate of approximately 1000ml per minute.


Output Characteristics Overview




Normal working voltage/current10.2~14.1V / 20A
Surface temperature< 60°C
Theoretical water consumptionabout 0.72ml/Min
Water consumption Without Hydrogen-water separationAbout 50-75ml/Min
