Alkaline Water Electrolysis: Principles, Technology, and Industrial Applications

Alkaline water electrolysis (AWE) stands as the most mature and commercially established technology for hydrogen production. As the global energy sector accelerates its transition towards net-zero emissions, this century-old method has experienced a renaissance, emerging as a cornerstone for large-scale green hydrogen projects 17. This guide explores the technical mechanisms, critical components, and evolving industrial landscape of alkaline electrolysers in the current market of 2026.

Fundamental Operating Principles

At its core, alkaline water electrolysis is an electrochemical process that splits water into hydrogen and oxygen using a direct electric current. Unlike other methods that may use acidic environments, AWE operates in a highly alkaline solution, typically potassium hydroxide (KOH) or sodium hydroxide (NaOH), with a concentration range of 20–30% 918.

The process occurs within a cell comprising two electrodes separated by a porous diaphragm. When a voltage is applied, water molecules are reduced at the cathode to produce hydrogen gas and hydroxide ions ($O{H}^{-}$). These ions travel through the diaphragm to the anode, where they are oxidised to form oxygen gas and water 9.

The essential chemical reactions are:

• Cathode (Reduction): $2H_{2}O+2e^{-}\to H_2+2O{H}^{-}$ 1

• Anode (Oxidation): $2O{H}^{-}\to \frac{1}{2}{O}_2+H_{2}O+2e^{-}$ 1

• Overall Reaction: $H_{2}O\to H_2+\frac{1}{2}{O}_2$ 1

The transport of hydroxide ions ($O{H}^{-}$) from the cathode to the anode is the critical ionic bridge that closes the electrical circuit, distinguishing it from Proton Exchange Membrane (PEM) electrolysis where protons ($H^{+}$) move in the opposite direction 1527.

Critical Components and Materials

The robust nature of alkaline electrolysers stems from their ability to utilise non-precious metals, which significantly lowers capital costs compared to alternative technologies.

• Electrodes: The electrodes are primarily nickel-based. Nickel is favoured for its stability in alkaline environments and decent catalytic activity for both hydrogen and oxygen evolution reactions. To enhance efficiency, modern electrodes are often coated with catalytic layers containing nickel, cobalt, or iron alloys to lower the overpotential and increase current density 110.

• Diaphragm: This is a semi-permeable separator that prevents the mixing of product gases ($H_2$ and $O_2$) while allowing the passage of hydroxide ions. Historically, asbestos was the standard material. However, due to health risks and regulatory bans, the industry has shifted to advanced composite materials. Zirfon—a composite of zirconia and polysulfone—has become the industry standard, offering superior durability, wettability, and low ionic resistance 59.

• Electrolyte: The liquid electrolyte, usually a 25-30% KOH solution, circulates through the system. It serves not only as the ionic conductor but also helps in thermal management by removing heat generated during electrolysis 18.

Technological Evolution: The Shift to Zero-Gap Design

Traditional alkaline electrolysers operated with a small gap between the electrodes and the diaphragm. While reliable, this design suffered from higher internal electrical resistance (ohmic loss) caused by gas bubbles accumulating in the gap and the distance ions had to travel 21.

Recent years have seen a definitive shift towards "Zero-Gap" architecture. in this modern design, porous electrodes are pressed directly against the diaphragm. This configuration minimises the distance between electrodes, significantly reducing ohmic resistance and allowing for operations at much higher current densities 2129. This evolution has been pivotal in making AWE competitive with PEM technology regarding efficiency and compactness, enabling modern alkaline systems to handle more variable power loads from renewable sources like wind and solar 36.

Comparative Analysis: AWE vs. PEM

While AWE is the market leader for capacity, it competes closely with Proton Exchange Membrane (PEM) electrolysis. The choice between them often depends on the specific project requirements.

AWE remains the preferred choice for large-scale, steady-state industrial applications where upfront expenditure (CAPEX) and longevity are the primary concerns. PEM is often favoured for projects requiring rapid response to highly volatile power grids or where space is severely constrained 1938.

Industrial Applications and Major Projects

As of early 2026, alkaline electrolysis dominates the project pipeline for large-scale green hydrogen production in Europe and globally. Its primary applications have expanded from niche chemical synthesis to decarbonising heavy industry.

• Green Ammonia and Fertilisers: The fertiliser industry, a massive consumer of grey hydrogen, is a prime adopter. For instance, the Yara plant uses alkaline electrolysers to replace fossil-fuel-based hydrogen, directly reducing carbon emissions in food production supply chains 18.

• Green Steel: The steel industry is undergoing a revolution by replacing coking coal with green hydrogen for direct reduction of iron ore. A flagship example is H2 Green Steel in Sweden, which placed an order for over 700 MW of alkaline electrolysis capacity from Thyssenkrupp nucera. This massive installation demonstrates the technology's capability to operate at the gigawatt scale necessary for heavy industry 2428.

• Grid Balancing and Energy Storage: Utilities are increasingly deploying large AWE modules to absorb excess renewable energy. RWE's pilot plant in Lingen, Germany, commissioned in mid-2024, utilises 14 MW of alkaline capacity to test fluctuating load operations, paving the way for GW-scale facilities planned for later this decade 34.

Future Outlook

The trajectory for alkaline water electrolysis is one of incremental optimisation rather than radical reinvention. Research in 2025 and 2026 has focused on improving the flexibility of AWE systems to better handle the intermittency of renewable energy—a traditional weakness compared to PEM. Innovations in electrode coatings and separator membranes are steadily widening the operational load range (e.g., operating efficiently at 10% to 110% of nominal load) 1236.

Furthermore, manufacturing capacity has surged. Major suppliers like Thyssenkrupp nucera and Nel Hydrogen have expanded their production lines to meet the multi-gigawatt demand projected by the EU’s 2030 hydrogen targets 2228. As the "workhorse" of the hydrogen economy, alkaline electrolysis is set to provide the bulk of the heavy lifting required to move global industries away from fossil fuels, proving that mature technology can indeed lead a modern revolution.
